45" x 11 3/4", WILLIS, 5 HP, pwr elev, #4 MT, 44-1500 RPM New w/ box table   Our stock number: 4483

45 x 11 3/4 , WILLIS, 5 HP, pwr elev, #4 MT, 44-1500 RPM New w/ box table

Inbound freight from Los Toledo, OH . . . . . . . . . . . . . . . .$ 1,000.00
From Stock: Ohio.
STANDARD ACCESSORIES:
5 HP, 220/440 volt, 3 phase, 60 Hz motor with switch and wiring complete
Power arm elevation
Box work table
Coolant system
Work light
Tool box with necessary wrenches and spanners
Instruction manual and parts list

SPECIFICATIONS:
Column diameter 11-3/4" (294mm)
Distance from spindle
center to column--minimum 13" (325mm)
--maximum 45" (1125mm)
nose to base--minimum 21" (525mm)
--maximum 48" (1200mm)
Horizontal travel--spindle head 32" (800mm)
Vertical travel of arm 27" (675mm)
Spindle speeds--number 12
--range 44 to 1500 rpm
Spindle taper #4MT
Quill travel 9-1/2" (238mm)
Quill powerfeed--number 3
--range .002/.0036/.006"
Drilling--cast iron 2-1/8" (53mm)
--mild steel 1-3/4" (44mm)
Work table dimension (L x W x H) 25-3/4" x 19-3/4" x 16"
(634mm x 434mm x 400mm)
Work area of base 28" x 50" (700 x 1250mm)
Motors--main spindle 5 HP
--arm elevating 2 HP
--coolant pump 1/8 HP
Power-electrical 60 Hz., 3 ph. 220/440 Volt
Dimensions (L x W x H) 30" x 72" x 86"
(750mm x 1800mm x 2150mm)
Machine net weight/Shipping 4620 lbs
