16", ELU, No. SA 103/25, swivel, 4-1/4" SQ, automatic, pneumatic, 1986   Our stock number: 5477

16 , ELU, No. SA 103/25, swivel, 4-1/4 SQ, automatic, pneumatic, 1986

Click on picture below for larger version
16 , ELU, No. SA 103/25, swivel, 4-1/4 SQ, automatic, pneumatic, 198616 , ELU, No. SA 103/25, swivel, 4-1/4 SQ, automatic, pneumatic, 198616 , ELU, No. SA 103/25, swivel, 4-1/4 SQ, automatic, pneumatic, 198616 , ELU, No. SA 103/25, swivel, 4-1/4 SQ, automatic, pneumatic, 1986

SPECIFICATIONS:
Blade diameter 16" (420mm)
Cut capacity--square 4-1/4" x 4-1/4"
Feed distances 3/16" to 24" (5 to 600mm)
Saw blade feed speed Infinitely variable
Saw blade mitre 0 to 45 degrees
Blade speed 2,600 FPM
Main motor 4.1 HP (3KW)
Electrics 230/460/3/60/50
Weight 800 lbs (360 Kg)
Dimensions (L x W x H) 108" x 54" x 58"

EQUIPPED WITH:
Fully automatic, Swivel head, Pneumatic clamps, Remote foot pedal
Minimum cycle times thanks to infinitely variable adjustment of the feed
Spray mist system, 10' length adjustable length stop, Conveyor table
